CA3101F14SA7PB08
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CIRCULAR, SIZE 14SA, 7WAYS, PIN
PDF
/
Inventory: 9599
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Max Operating Temperature 125°C
Number of Positions 7
Connector Type Receptacle, Male Pins
Termination Solder Cup
Part Status Active
Series MIL-DTL-5015, CA-B
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Contact Style Pin
Number of Contacts 7
Shell Size - Insert 14S-A7
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Current Rating (Amps) 22A
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Male
Color Olive Drab
Min Operating Temperature -55°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Silver
Contact Material Copper
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
