CA3101E36A46SB

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 4023
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Feature Strain Relief
Part Status Active
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 27
Color Olive Drab
Gender Female
Voltage - Rated 50V
HTS Code 8536.69.40.20
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 27
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 36-A46
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Body/Shell Style PLUG
Environmental Characteristics CORROSION RESISTANT

Compliance

RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
