CA3101E36A46PBF80
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 9295
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Feature Strain Relief
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 27
Color Olive Drab
Gender Male
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 27
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 36-A46
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Body/Shell Style PLUG
Environmental Characteristics CORROSION RESISTANT
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
