CA3101E20-29PDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3101E20-29PDN Circular Connector, MIL-C-5015 Series (VG95234), Plug, 17, Pin, Crimp, Cable
PDF
/
Buying Options
Total Price: USD $60.56
Unit Price: USD $60.5616
≥1 USD $60.5616
≥10 USD $52.4832
≥100 USD $46.3144
≥500 USD $41.4392
≥1000 USD $36.3352
Inventory: 129
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics CORROSION RESISTANT
Body/Shell Style PLUG
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 20-29
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 17
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Male
Color Olive Drab
Number of Positions 17
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Feature Shrink Boot Adapter
Series MIL-DTL-5015, CA
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
