CA3101E14S-2PXB06
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 4POS SOLDER CUP
PDF
/
Inventory: 3720
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA-B
JESD-609 Code e4
Feature Shrink Boot Adapter
Pbfree Code no
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 4
Color Olive Drab
Gender Male
Voltage - Rated 50V
Additional Feature STANDARD:MIL-C-5015
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 4
Orientation X
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 22A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 14S-2
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Body/Shell Style PLUG
Environmental Characteristics ENVIRONMENT RESISTANT
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
