CA3100ER24-11PF80
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3100ER24-11PF80Circular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 9 Contacts
PDF
/
Inventory: 4705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Silver
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-5015, CA
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 9
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Threaded
Contact Finish - Mating Silver
Current Rating (Amps) 41A 74A
Orientation N (Normal)
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 74A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 24-11
Number of Contacts 9
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
