CA3100E36A46PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 27POS SOLDER CUP
PDF
/
Inventory: 8019
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics CORROSION RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 36-A46
Shell Finish Olive Drab Cadmium
Current Rating 41A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Total Number of Contacts 27
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
HTS Code 8536.69.40.20
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 27
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA-B
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
