CA3100E32-15PB02
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3100E32-15PB02Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 8 Contacts
PDF
/
Inventory: 3319
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Body Plating Cadmium
Contact Style Pin
Shell Size - Insert 32-15
Shell Finish Olive Drab Cadmium
Current Rating 245A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Current Rating (Amps) 41A 245A
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 8
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series MIL-DTL-5015, CA-B
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper
