CA3100E24-22PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3100E24-22PB Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 4
PDF
/
Inventory: 2817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Contact Style Pin
Shell Size - Insert 24-22
Shell Finish Olive Drab Cadmium
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Current Rating (Amps) 74A
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 4
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA-B
Published 2012
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
