CA3100E22-22PB05-15

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN RCPT MALE 4POS SILVER CRIMP
PDF
/
Inventory: 3018
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 22-22
Shell Finish Olive Drab Cadmium
Current Rating 74A
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 4
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series MIL-DTL-5015, CA-B
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
