CA3100E22-14SB01
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT 19POS WALL MNT SKT
PDF
/
Inventory: 4827
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Feature Strain Relief
Part Status Active
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 19
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 19
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 22A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 22-14
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics CORROSION RESISTANT
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
