CA3100E18-8SWB15
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 8POS SILVR CRIMP
PDF
/
Inventory: 7456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Coupling Type THREADED
Environmental Characteristics ENVIRONMENT RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 18-8
Shell Finish Olive Drab Cadmium
Current Rating 41A
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Shielded
Orientation W
Total Number of Contacts 8
Current Rating (Amps) 22A 41A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 8
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series MIL-DTL-5015, CA-B
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper
