CA3100E16-7PW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 3POS SOLDER CUP
PDF
/
Inventory: 4596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA
Feature Strain Relief
Pbfree Code no
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 3
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Additional Feature STANDARD: MIL-C-5015
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Current Rating (Amps) 22A 74A
Total Number of Contacts 3
Orientation W
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 74A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16-7
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics CORROSION RESISTANT
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
