CA3100E14S-7SWB02

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA3100E14S-7SWB02Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 3 Contacts
PDF
/
Inventory: 2544
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Body Plating Cadmium
Coupling Type THREADED
Environmental Characteristics ENVIRONMENT RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 14S-7
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation W
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 3
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code no
Feature Shrink Boot Adapter
JESD-609 Code e4
Series MIL-DTL-5015, CA-B
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
