CA3100E14S-4PB08

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA3100E14S-4PB08 Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 1
PDF
/
Inventory: 4774
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Body Plating Cadmium
Contact Style Pin
Shell Size - Insert 14S-4
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
HTS Code 8536.69.40.20
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 1
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA-B
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount, Right Angle
Mount Flanges, Panel
Contact Material Copper
