CA3100E14S-11PB09
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3100E14S-11PB09Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 4 Contacts
PDF
/
Buying Options
Total Price: USD $53.42
Unit Price: USD $53.422196
≥1 USD $53.422196
≥10 USD $50.398293
≥100 USD $47.545564
≥500 USD $44.854307
≥1000 USD $42.315388
Inventory: 3788
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Body Plating Cadmium
Number of Contacts 4
Shell Size - Insert 14S-11
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Current Rating (Amps) 22A
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Solder Cup
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA-B
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount, Right Angle
Mount Flanges, Panel, Through Hole
Contact Plating Silver
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
