CA20COML18-1SB

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA20COML18-1SB Circular Connector, CA-COM-B Series, MIL-DTL-5015 Series Equivalent, Box Mount Receptacle, 10
PDF
/
Inventory: 2573
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 18-1
Shell Finish Nickel
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Total Number of Contacts 10
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
HTS Code 8536.69.40.20
Gender Receptacle
Applications Automotive, Aviation, Industrial, Instrumentation, Military, Telecom
Number of Positions 10
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Part Status Active
Series MIL-DTL-5015, CA-COM-B
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Insert Material Polychloroprene
Shell Material Aluminum Alloy and Zinc Die Cast
Mounting Feature Flange
Mounting Type Panel Mount, Through Hole
Mount Cable, Flanges, Panel, Through Hole
Contact Material Copper Alloy
