CA08COMF20-27PF80-44

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA08COMF20-27PF80-44 Circular Connector, CA-COM Series, MIL-DTL-5015 Series Equivalent, Right Angle Plug, 14, Crimp Pin
PDF
/
Inventory: 6440
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Body Plating Nickel
Number of Contacts 14
Shell Size - Insert 20-27
Shell Finish Nickel
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Current Rating (Amps) 22A
Contact Finish - Mating Silver
Fastening Type Threaded
Gender Receptacle
Applications Automotive, Aviation, Industrial, Instrumentation, Military, Telecom
Color Silver
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 14
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series MIL-DTL-5015, CA-COM
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Insert Material Polychloroprene
Shell Material Aluminum Alloy and Zinc Die Cast
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Silver
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 12 Weeks
