CA07A20A9PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 9POS SOLDER CUP
PDF
/
Inventory: 964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-5015, CA-B
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 9
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 9
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 20-A9
Empty Shell YES
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
