CA06R22-2SWF80

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA06R22-2SWF80 Circular Connector, MIL-C-5015 Series (VG95342), Receptacle, 3 Contacts, Socket, Crimp, Cable Mount
PDF
/
Inventory: 993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Technical

Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 22-2
Shell Finish Olive Drab Cadmium
Current Rating 74A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation W
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Number of Positions 3
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
