CA06PG14S-6SB

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG FMALE 6POS SOLDER CUP
PDF
/
Inventory: 5896
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Part Status Active
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 6
Color Olive Drab
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 22A
Total Number of Contacts 6
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Shell Finish Olive Drab Cadmium
Shell Size - Insert 14S-6
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT

Compliance

RoHS Status Non-RoHS Compliant
