CA02COME20-4PB01A176
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 2192
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy and Zinc Die Cast
Insert Material Polychloroprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA-COM-B
Feature Strain Relief
Part Status Active
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 4
Color Silver
Applications Automotive, Aviation, Industrial, Instrumentation, Military, Telecom
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Nickel
Shell Size - Insert 20-4
Empty Shell YES
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 19.7μin 0.50μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
