CA01PG28A16PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 9POS SOLDER CUP
PDF
/
Inventory: 7824
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 9
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Current Rating (Amps) 22A 135A
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 135A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 28-A16
Number of Contacts 20
Empty Shell NO
Backshell Type SOLID
Body/Shell Style PLUG
Environmental Characteristics CORROSION RESISTANT
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
