CA01PG16S-1SB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 7POS SOLDER CUP
PDF
/
Inventory: 9256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Number of Contacts 7
Shell Size - Insert 16S-1
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Current Rating (Amps) 22A
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Receptacle
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 7
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Series MIL-DTL-5015, CA-B
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Silver
Contact Material Copper
