CA01COMPG22-14SB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 2898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy and Zinc Die Cast
Insert Material Polychloroprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA-COM-B
Part Status Active
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 19
Applications Automotive, Aviation, Industrial, Instrumentation, Military, Telecom
HTS Code 8536.69.40.20
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 19
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 22A
Shell Finish Nickel
Shell Size - Insert 22-14
Empty Shell YES
Backshell Type SOLID
Body/Shell Style PLUG
Compliance
RoHS Status RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
