CA00COMPG22-14PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA00COMPG22-14PBCircular Connector, CA-COM-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle
PDF
/
Inventory: 6360
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy and Zinc Die Cast
Insert Material Polychloroprene
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2000
Series MIL-DTL-5015, CA-COM-B
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 19
Applications Automotive, Aviation, Industrial, Instrumentation, Military, Telecom
Gender Receptacle
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 19
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 22A
Shell Finish Nickel
Shell Size - Insert 22-14
Empty Shell YES
Backshell Type SOLID
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
