BFR16S1S1
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
MIL-C-5015POLARIZED Circular Connector
PDF
/
Inventory: 6868
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-C-5015, BFR
Pbfree Code no
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Olive Drab
Gender Female
Voltage - Rated 500VAC 700VDC
Additional Feature MIL-C-5015 POLARIZED
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 7
Orientation N (Normal)
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16S-1
Empty Shell NO
Max Current Rating 22A
Dimensions
Length 31.17mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
