RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors - Housings
Description Circular Metric Connectors SF-7EP1N8A9LB3
PDF
/
Inventory: 1154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Fastening Type Push-Twist
Contact Type Crimp
Orientation N (Normal)
Shielding Shielded
Number of Positions 8 (4 + 3 Power + PE)
Type For Male Pins
Connector Type Receptacle Housing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series SF
Published 2013
Packaging Bulk
Operating Temperature -40°C~125°C
Thread Size M23
Contact Size 1.0mm 4 2.0mm Power 4
Note Contacts Not Included
Housing Color Silver
Contact Gender Male
Shell Size - Insert M23-8
Reach Compliance Code not_compliant
Ingress Protection IP67 - Dust Tight, Waterproof

Physical

Insert Material Polyamide (PA66), Nylon 6/6
Weight 53.789988g
Shell Material Gadolinium-Zinc
Contact Shape Circular
Number of Pins 8
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Factory Lead Time 5 Weeks

Compliance

Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
