TVS06RF-25-35S-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors - Housings
Description
AMPHENOL TVS06RF-25-35S-LC Circular Connector, Tri-Start TV Series, MIL-DTL-38999 Series III Equivalent, Straight Plug, 128
PDF
/
Buying Options
Total Price: USD $71.6
Unit Price: USD $71.5968
≥1 USD $71.5968
≥10 USD $62.04968
≥100 USD $54.749376
≥500 USD $48.986256
≥1000 USD $42.957112
Inventory: 721
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Gold
Mounting Type Free Hanging (In-Line)
Contact Shape Circular
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug Housing
Type For Female Sockets
Number of Positions 128
Gender Male
Additional Feature STANDARD: MIL-DTL-38999, POLARIZED, COMPATIBLE CONTACT: M39029/56-348
HTS Code 8536.69.40.20
Fastening Type Threaded
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Contact Type Crimp
Option GENERAL PURPOSE
Total Number of Contacts 128
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 25-35
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Silver
Empty Shell YES
Note Contacts Not Included
Contact Size 22D
Environmental Characteristics CORROSION/ENVIRONMENT/MOISTURE/VIBRATION RESISTANT
Plating Electroless Nickel
Body Plating Electroless Nickel
Dimensions
Length 31.34mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
