M90-3101F14S-2S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 4P CABLE SOCKET MIL-C-5015 COMPTBL
PDF
/
Inventory: 952
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Insert Material Polychloroprene
Backshell Material, Plating Aluminum Alloy, Black Zinc Chromate
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2009
Series M90
JESD-609 Code e4
Feature Backshell, Cable Clamp
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 4
Color Black
Gender Receptacle
Additional Feature POLARIZED
Fastening Type Threaded
Voltage - Rated DC 250V
Contact Finish - Mating Silver
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation Keyed
Shielding Unshielded
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 13A
Military Standard MIL-DTL-5015
Shell Finish Black Chromate over Zinc
Shell Size - Insert 14S-2
Voltage - Rated AC 200V
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics ENVIRONMENT RESISTANT
Plating Chromate
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 22 AWG
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
