21033412425
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT 2POS PNL MNT SKT
PDF
/
Buying Options
Total Price: USD $39.45
Unit Price: USD $39.4504
≥1 USD $39.4504
≥10 USD $36.20232
Inventory: 91
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Brass
Mount Bulkhead, Free Hanging, Front Side Nut, Panel
Mounting Type Free Hanging (In-Line); Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Zinc Die Cast
Insert Material Polyamide (PA), Nylon
Backshell Material, Plating Zinc Die Cast
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series Harax? M12
Feature Backshell
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle, Female Sockets
Number of Positions 2
Color Silver
Voltage - Rated 32V
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation B
Shielding Shielded
Ingress Protection IP65/67 - Dust Tight, Water Resistant, Waterproof
Current Rating 4A
Shell Size - Insert M12-2
Cable Opening 0.276 ~ 0.346 (7.00mm ~ 8.80mm)
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP65, Water Resistant, Waterproof
