MS24266R20T25PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 4628
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 12
Shell Material Aluminum
Insert Material Epoxy, Glass Filled
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series Military, MIL-DTL-26500
Feature Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 25 (Power)
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Sealed
Shell Finish Anodized
Shell Size - Insert 20-25
Shell Size, MIL G
Cable Opening 1.033 (26.24mm)
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Sealed
