MS24266R16T24P8
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE 24POS GOLD CRIMP
PDF
/
Inventory: 6945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.769 (19.53mm)
Shell Size, MIL E
Number of Contacts 24
Shell Size - Insert 16-24
Shell Finish Anodized
Ingress Protection Environment Sealed
Shielding Unshielded
Orientation 8
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Number of Positions 24 (Power)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series Military, MIL-DTL-26500
Published 2002
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Body Material Aluminium
Insert Material Epoxy, Glass Filled
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
