MS24266R14B12PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE 12POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $76.27
Unit Price: USD $76.274372
≥1 USD $76.274372
≥10 USD $71.956959
≥100 USD $67.883925
≥500 USD $64.041434
≥1000 USD $60.416445
Inventory: 1641
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 16
Shell Material Aluminum
Insert Material Epoxy, Glass Filled
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series Military, MIL-DTL-26500
Feature Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 12
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 12 (Power)
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Sealed
Shell Finish Anodized
Shell Size - Insert 14-12
Plating Aluminium, Anodized
Number of Ports 1
Shell Size, MIL D
Cable Opening 0.664 (16.87mm)
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Sealed
