MS24265R16B24PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Buying Options
Total Price: USD $134.86
Unit Price: USD $134.864435
≥1 USD $134.864435
≥10 USD $127.230594
≥100 USD $120.028864
≥500 USD $113.234782
≥1000 USD $106.825262
Inventory: 8818
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Shell Size, MIL E
Number of Ports 1
Plating Aluminium, Anodized
Shell Size - Insert 16-24
Shell Finish Anodized
Ingress Protection Environment Sealed
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Number of Positions 24 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-26500
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Insert Material Epoxy, Glass Filled
Shell Material Aluminum
Number of Pins 20
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 12 Weeks
