MS24264R22B19P8
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 19POS GOLD CRIMP
PDF
/
Inventory: 2779
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Epoxy, Glass Filled
Body Material Aluminium
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Published 2002
Series Military, MIL-DTL-26500
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 19 (Power)
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation 8
Shielding Unshielded
Ingress Protection Environment Sealed
Military Standard MIL-DTL-26500
Shell Finish Anodized
Shell Size - Insert 22-19
Number of Contacts 19
Shell Size, MIL H
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Sealed
