C0909A12-03P7-402
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 1387
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.580 (14.73mm)
Shell Size - Insert 12-3
Shell Finish Anodized
Military Standard MIL-DTL-26500
Ingress Protection Environment Sealed
Orientation 7
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Number of Positions 3 (Power)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series MIL-DTL-26500, C0909A
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Shell Material Aluminum
Number of Pins 3
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 12 Weeks
