BACC63CC16-10S9
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 10POS GOLD CRIMP
PDF
/
Inventory: 5621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.758 (19.25mm)
Number of Contacts 10
Shell Size - Insert 16-10
Shell Finish Cadmium over Nickel
Military Standard MIL-DTL-26500
Ingress Protection Environment Sealed
Shielding Shielded
Orientation 9
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Min Operating Temperature -55°C
Max Operating Temperature 200°C
Number of Positions 10 (Power)
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series MIL-DTL-26500, BACC63
Published 2002
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
