BACC63BV22F32SN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 32POS GOLD CRIMP
PDF
/
Inventory: 9568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Published 2002
Series MIL-DTL-26500, BACC63
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 32 (Power)
Max Operating Temperature 200°C
Min Operating Temperature -55°C
Gender Receptacle
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Sealed
Military Standard MIL-DTL-26500
Shell Finish Cadmium over Nickel
Shell Size - Insert 22-32
Number of Contacts 32
Cable Opening 1.106 (28.09mm)
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Sealed
