BACC63BV20B16PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 16POS GOLD CRIMP
PDF
/
Inventory: 3553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.986 (25.04mm)
Number of Contacts 16
Shell Size - Insert 20-16
Military Standard MIL-DTL-26500
Ingress Protection Environment Sealed
Shielding Shielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Number of Positions 16 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-26500, BACC63
Published 2002
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Body Material Aluminium, Stainless Steel
Shell Material Stainless Steel
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
