BACC63BV18H8P7 image
Favorite
BACC63BV18H8P7 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN RCPT MALE 8POS GOLD CRIMP
PDF
/
Inventory: 8506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Cable Opening 0.865 (21.97mm)
Number of Contacts 8
Shell Size - Insert 18-8
Shell Finish Anodized
Military Standard MIL-DTL-26500
Ingress Protection Environment Sealed
Shielding Shielded
Orientation 7
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Min Operating Temperature -55°C
Max Operating Temperature 200°C
Number of Positions 8 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series MIL-DTL-26500, BACC63
Published 2002
Packaging Bulk
Operating Temperature -55°C~200°C

Physical

Body Material Aluminium
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
