BACC63BV14F3PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 6190
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.609 (15.47mm)
Shell Size - Insert 14-3
Shell Finish Cadmium over Nickel
Ingress Protection Environment Sealed
Shielding Shielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Threaded
Min Operating Temperature -55°C
Max Operating Temperature 200°C
Number of Positions 3 (1 + 2 Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series MIL-DTL-26500, BACC63
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Shell Material Aluminum
Number of Pins 3
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Supply Chain
Factory Lead Time 12 Weeks
