RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG MALE 57POS GOLD CRIMP
PDF
/
Inventory: 3647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Stainless Steel
Body Material Aluminium, Stainless Steel

Technical

Operating Temperature -55°C~200°C
Packaging Bulk
Published 2002
Series MIL-DTL-26500, BACC63
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 57 (Power)
Max Operating Temperature 200°C
Min Operating Temperature -55°C
Gender Male
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Sealed
Military Standard MIL-DTL-26500
Shell Size - Insert 24-57
Number of Contacts 57
Body Plating Passivated
Cable Opening 1.235 (31.37mm)

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Sealed
