BACC63BP22D12PN image
Favorite
BACC63BP22D12PN image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG MALE 12POS GOLD CRIMP
PDF
/
Inventory: 9713
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Sealed
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Cable Opening 1.106 (28.09mm)
Number of Contacts 12
Shell Size - Insert 22-12
Military Standard MIL-DTL-26500
Ingress Protection Environment Sealed
Shielding Shielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Male
Min Operating Temperature -55°C
Max Operating Temperature 200°C
Number of Positions 12 (Power)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-26500, BACC63
Published 2002
Packaging Bulk
Operating Temperature -55°C~200°C

Physical

Body Material Aluminium, Stainless Steel
Shell Material Stainless Steel
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
