24003231-02
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
LARGE SERIES 3PIN MALE PLUG WITH
PDF
/
Buying Options
Total Price: USD $12.14
Unit Price: USD $12.144
≥1 USD $12.144
≥10 USD $10.76328
≥100 USD $10.3488
≥500 USD $9.935024
≥1000 USD $9.383088
≥3000 USD $8.555149
Inventory: 579
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Brass, Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Shell Material Polyamide (PA66), Nylon 6/6
Insert Material Polyamide (PA66), Nylon 6/6
Backshell Material, Plating Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -45°C~105°C
Packaging Bulk
Series Large
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 3
Color Black, Yellow
Applications Communication Systems, Industrial, Lighting, Marine
Voltage - Rated 300V
Fastening Type Push-Twist
Contact Finish - Mating Gold
Current Rating (Amps) 20A
Orientation Keyed
Shielding Unshielded
Ingress Protection IP67 - Dust Tight, Waterproof
Cable Opening 0.256 ~ 0.413 (6.50mm ~ 10.50mm)
Compliance
RoHS Status ROHS3 Compliant
