22005231-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD SERIES 5PIN MALE PLUG W
PDF
/
Buying Options
Total Price: USD $6.93
Unit Price: USD $6.9256
≥1 USD $6.9256
≥10 USD $6.23392
≥100 USD $5.872416
≥500 USD $5.721936
≥1000 USD $5.571368
≥3000 USD $5.302
Inventory: 246
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Brass, Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Shell Material Polyamide (PA66), Nylon 6/6
Insert Material Polyamide (PA66), Nylon 6/6
Backshell Material, Plating Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -45°C~105°C
Packaging Bulk
Series Standard
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 5
Color Black, Yellow
Applications Communication Systems, Industrial, Lighting, Marine
Voltage - Rated 60V
Fastening Type Push-Twist
Contact Finish - Mating Gold
Current Rating (Amps) 5A
Orientation Keyed
Shielding Unshielded
Ingress Protection IP67 - Dust Tight, Waterproof
Cable Opening 0.138 ~ 0.268 (3.50mm ~ 6.80mm)
Compliance
RoHS Status ROHS3 Compliant
