AP-6-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
PLASTIC PLUG STR CORD 6 SKT
PDF
/
Buying Options
Total Price: USD $21.11
Unit Price: USD $21.1112
≥1 USD $21.1112
≥10 USD $18.48792
≥100 USD $17.689056
≥500 USD $17.118288
≥1000 USD $16.547696
≥3000 USD $15.634696
Inventory: 179
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Cable
Mounting Type Free Hanging (In-Line)
Shell Material Polyphenylene Ether (PPE), Modified
Housing Material Thermoplastic
Insert Material Polybutylene Terephthalate (PBT)
Backshell Material, Plating Thermoplastic
Technical
Operating Temperature -25°C~75°C
Packaging Bulk
Published 2006
Series AP
Feature Backshell, Cable Clamp
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 6
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Color Black
Applications Audio
Gender Female
Voltage - Rated 200V
Fastening Type Latch Lock
Contact Finish - Mating Tin
Current Rating (Amps) 20A
Orientation Keyed
Shielding Unshielded
Ingress Protection IP40
Current Rating 20A
Shell Finish Black
Number of Contacts 6
Contact Resistance 3mOhm
Insulation Resistance 1GOhm
Wire/Cable Gauge 12 AWG
Cable Opening 0.433 ~ 0.669 (11.00mm ~ 17.00mm)
Dimensions
Diameter 28.8mm
Length 98.7mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
