Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Buying Options
Total Price: USD $30.11
Unit Price: USD $30.108736
≥1 USD $30.108736
≥200 USD $12.014348
≥500 USD $11.612601
≥1000 USD $11.414353
Inventory: 4875
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Brass
Contact Plating Gold, Silver
Mount Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Bulkhead - Front Side Nut
Shell Material Brass
Housing Material Bronze
Insert Material Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -30°C~80°C
Packaging Bulk
Series AG
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug, Female Sockets
Number of Positions 4
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Color Silver
Applications Audio
Gender Female
Voltage - Rated 1kV
Fastening Type Latch Lock
Contact Finish - Mating Gold
Current Rating (Amps) 5A
Orientation Keyed
Shielding Unshielded
Ingress Protection IP40
Current Rating 5A
Shell Finish Nickel
Shell Size - Insert Mini XLR
Plating Nickel

Dimensions

Length 18mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
