M12A-04PFFC-SF8B15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CBL FMALE TO WIRE LEAD 4P 0.49'
PDF
/
Buying Options
Total Price: USD $8.32
Unit Price: USD $8.316
≥1 USD $8.316
≥10 USD $7.48792
≥100 USD $6.692224
≥500 USD $4.955861
Inventory: 200
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Zinc Alloy
Insert Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2016
Series M
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Connector Type Receptacle, Female Sockets
Number of Positions 4
Color Silver
Voltage - Rated 250VAC/DC
Fastening Type Threaded
Contact Finish - Mating Gold
Current Rating (Amps) 4A
Orientation A
Shielding Shielded
Ingress Protection IP68/69K - Dust Tight, Water Resistant, Waterproof
Shell Finish Nickel
Shell Size - Insert M12-4
Cable Length 150mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
