SP06CE-8-4P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3188
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Insert Material Neoprene
Backshell Material, Plating Aluminum, Anodic Coating (Alumilite)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-26482 Series I, SP
Feature Backshell, Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 4
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Anodic Coating (Alumilite)
Shell Size - Insert 8-4
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
